Super Anti-Weathering Powder Coatings for Outdoor Facilities in Different Colors
Product Description
This product issynthesized by hydroxy polyesters,sealing type of multi cyanogens ester, pigment and other additives. It iswidely used with great advantages as following:
•corrosion resisting
•super anti-weathering
•excellent leveling after coating
•easy application
•heavy metal-free
•without limitation of color choices
•applicable for outdoor facilities
Utilities:
•construction materials, such as aluminum profile, zinccoated steel, etc.
•poles and signs on roadside
•automobile parts
•outdoor furniture,
•outdoor facilities, fences
•outdoor lanterns, lights poles
•agricultural machines and outdoor machines
•outdoor recreational facilities
| Physical properties | Gravity | 1.4-1.7,up to color and gloss |
|
| Grit size | 100% smaller than 100μm, special requirement should be informed |
| Mobility | 120-140 |
| Properties of Coating layer | Item | criteria | result |
|
| Gloss 60° |
| GB/T9754-88 | 1° to 95°+ |
| Impact test | ISO6272 | GB/T1723-1993 | 1250px/kg |
| Cupping test | ISO1520 | GB/T9753-1988 | 6-8mm |
| Adhesion | ISO2409 | GB/T 9286-1998 | Grade 0 |
| Bending test | ISO1519 | GB/T 6742-1986 | 2mm |
| Pencil hardness | ASTMD3363 | GB/T 6739-1996 | 1-2H |
| Salt-fog test | ISO7253 | GB/T 1771-1991 | ＞500h |
| Anti-humidity | ISO6270 | GB/T 1740-1979 | ＞1000h |
| Heat resistance | △E 0.2-0.4 | Excellent gloss retention, 99% |
Attention:
1. Above parameters are gained from oil-free, rust removal cold rolling steel board of thickness of 0.8mm, under experimental circumstances, with coating layer thickness of 70μm;
2. The property data may drop down a little upon gloss reduction.
| Application conditions: | Consolidation | Standard | 185℃(work piece temperature) 15min |
| conditions | consolidation |
| Pre-treating | Pre-treating methods differs from different substrates( phosphating process, sand blasting, shot treatment) |
| Spraying | Corona electrostatic spraying ; frictional electrostatic spraying ; static electricity spraying fluidized bed (user must propose requirement); Fluidized bed hot – dip coating (user must propose requirement ); for other spraying method (user must propose requirement ahead) |
| Theoretical coverage | 8-10m2/kg, coating layer thickness60um, up to types and colors |
| Application confine | Outdoor and some for indoor |
| Packaging and transportation | 20Kg/Carton, with polyethylene bag, Non-dangerous articles, transportation friendly. Avoiding straight sunlight, humidity, heat, and contact with chemical substances; |
| Storing | Stored indoors at 40℃, ventilated, dry, clean warehouse, avoiding fire source, heat radiators, straight sunlight, opening to the air. Warranty period: 6 months. To be used after checking if expired. Unfinished bags should be sealed after opening. |
| Hygiene and security | Container or bags should be sealed after working. Keep away from fire source. Avoiding intake of powder. Catering and smoking are forbidden in relevant warehouse. Labor should wear anti-static shoes, keep grounding. |
We do not recommend use of bright color series such as yellow, orange, red, or metallic color series. For details, please contact us. In order to protect metal parts, pre-treating must be done in good quality before coating. For details, please contact supplier of pre-treating chemicals.
